AUXILIARY JACK INSPECTION

id092000812600

1.  Connect a commercially-available nonresistant plug to the auxiliary jack.

abs0zw00000117

2.  Verify that the continuity between the auxiliary jack terminals is as indicated in the table.

am2zzw00002026

•  If not as indicated in the table, replace the auxiliary jack.
