1. Component views
Rear axle
Part name
- Brake drum
- Oil catcher
- Wheel pin
- Axle shaft
- Bolt
- Rear drum brake
- Hub outer oil seal
- Bearing holder
- double taper roller bearing
- Exciter ring or retainer
- Shim
- Snap ring
- Rear axle shaft and rear drum brake
- axle case oil seal
- Nut
- Drain plug
- Gasket
- Filler plug
- Gasket
- Rear axle case
- Rear differential
- Bolt
- Nut
Tightening torque
15: 122 N・m { 12.4 kgf・m / 90 lb・ft }
16: 78 N・m { 8.0 kgf・m / 58 lb・ft }
18: 78 N・m { 8.0 kgf・m / 58 lb・ft }
22: 73 N・m { 7.4 kgf・m / 54 lb・ft }
23: 64 N・m { 6.5 kgf・m / 47 lb・ft }
2. Exciter ring removal
1. ABS specifications
1) Remove the snap ring from the rear axle shaft using snap ring pliers.
Caution
- Do not reuse the snap ring.
2) Remove the shim from the rear axle shaft.
Note
- If any shims are installed, remove them.
3) Grind the exciter ring surface using a grinder.
4) Remove the exciter ring from the rear axle shaft using a chisel.
Caution
- Do not reuse the exciter ring.
3. Rear axle shaft disassembly
1. ABS specifications
1) Install the special tool to the rear axle shaft.
SST: 5-8840-2831-0 - axle shaft bearing remover
Legend
- 5-8840-2831-0
2) Remove the following parts from the rear axle shaft using a press.
- double taper roller bearing
- Oil seal
- Bearing holder
- Back plate
Caution
- Do not reuse the following parts.
- double taper roller bearing
- Snap ring
Legend
- Press fitting
- Bearing remover
- Exciter ring
- double taper roller bearing
- Back plate
- Oil seal
- Rear axle shaft
3) Remove the hub outer oil seal from the bearing holder.
4) Remove the double taper roller bearing outer race from the bearing holder.
Note
- If the double taper roller bearing outer race cannot be removed by hand, use the special tool for removal.
SST: 5-8840-2119-0 - installer: inner bearing
SST: 5-8840-0007-0 - grip
Legend
- 5-8840-2119-0
- 5-8840-0007-0
5) Remove the wheel pin from the rear axle shaft using the special tool.
SST: 5-8840-0079-0 - wheel pin remover
Legend
- 5-8840-0079-0
6) Remove the oil catcher from the rear axle shaft.
Legend
- Rear axle shaft
- Oil catcher
2. Except ABS specifications
1) Remove the snap ring from the rear axle shaft using snap ring pliers.
Caution
- Do not reuse the snap ring.
2) Remove the shim from the rear axle shaft.
Note
- If any shims are installed, remove them.
3) Grind the retainer surface using a grinder.
4) Remove the retainer from the rear axle shaft using a chisel.
Caution
- Do not reuse the retainer.
5) Install the special tool to the rear axle shaft.
SST: 5-8840-2831-0 - axle shaft bearing remover
Legend
- 5-8840-2831-0
6) Remove the following parts from the rear axle shaft using a press.
- double taper roller bearing
- Oil seal
- Bearing holder
- Back plate
Caution
- Do not reuse the following parts.
- double taper roller bearing
- Snap ring
Legend
- Press fitting
- Bearing remover
- Retainer
- double taper roller bearing
- Back plate
- Oil seal
- Rear axle shaft
7) Remove the hub outer oil seal from the bearing holder.
8) Remove the double taper roller bearing outer race from the bearing holder.
Note
- If the double taper roller bearing outer race cannot be removed by hand, use the special tool for removal.
SST: 5-8840-2119-0 - installer: inner bearing
SST: 5-8840-0007-0 - grip
Legend
- 5-8840-2119-0
- 5-8840-0007-0
9) Remove the wheel pin from the rear axle shaft using the special tool.
SST: 5-8840-0079-0 - wheel pin remover
Legend
- 5-8840-0079-0
10) Remove the oil catcher from the rear axle shaft.
Legend
- Rear axle shaft
- Oil catcher
