INTAKE MANIFOLD [SKYACTIV-D 2.2]

id0113z7003700

Purpose, Function

• Distributes intake air to each cylinder evenly.

• Optimizes the combustion efficiency and performance of the engine by distributing intake air to each cylinder.

Construction

• The intake manifold is installed to the cylinder head.

Fuel injector (2pin type)

ac5wzn00001937

Fuel injector (6pin type)

ac8wzn00000137
