STEERING SHAFT CONSTRUCTION


id061400100300

•  Due to the adoption of a tilt/telescope mechanism for the steering shaft on all vehicles, operability has been improved.
•  The tilt/telescope mechanism has a movement range of 45 mm {1.8 in} (tilt) / 50 mm {2.0 in} (telescope) and can be adjusted, without steps, to anywhere in this range.
ac9wzn00000231
