FRONT SIDE FRAME COMPONENT REMOVAL [PANEL REPLACEMENT]

id098008741900

1.  Rough cut area (A), drill the 21 locations indicated by (B).

ac9uub00000091

2.  Drill the 2 locations indicated by (C), and remove the front side frame component.

Note

•   The 2 weld locations indicated by (C) cannot be seen from the interior.

am8rrb00000035
