CONNECTIVITY MASTER UNIT (CMU) DISASSEMBLY/ASSEMBLY

id092000700700

1.  Disassemble in the order shown in the figure.

a30zzw00000180

1	Screw
2	Bracket A
3	Screw
4	Bracket B
5	CMU

2.  Assemble in the reverse order of disassembly.
