ADAPTIVE LED HEADLIGHT SWITCH INSPECTION [(E)]

id1520000211x2

1.  Disconnect the negative lead-acid battery terminal. (See NEGATIVE LEAD-ACID BATTERY TERMINAL DISCONNECTION/CONNECTION.)

2.  Remove the light switch. (See LIGHT SWITCH REMOVAL/INSTALLATION.)

3.  Verify that the continuity between the high beam control switch terminals is as indicated in the table.

a30zzw00006712
