FRONT FRAME COMPONENT (FRONT) REMOVAL

D5E098053300B11

1. Drill the 2 locations indicated by (A).

Note

• To prevent damage to the front side frame rear reinforcement, grind it using a belt grinder from the front side.

2. Remove the front frame component (front).
