TRANSMITTER ID CODE REGISTRATION

Type A

Applied VIN (assumed):

• JMZ NC1882*# 100001-103859

• JMZ NC18820# 100001-103859

• JMZ NC18F2*# 100001-103859

• JMZ NC18F20# 100001-103859

• JMZ NC18F6*# 100001-103859

• JMZ NC18F60# 100001-103859

• JM0 NC30F100 100001-100545

Caution

• If the programming mode is activated with one or two programmed ID codes and operation or programming of the transmitter is attempted, the programming operation is disabled and the programming mode is cancelled.

• If a button other than the transmitter UNLOCK button is operated, the programming operation is disabled and the programming mode is cancelled.

Note

• When clearing all the programmed ID codes, program three ID codes using an unprogrammed transmitter to terminate the programming mode, then reactivate the programming mode.

• A maximum of three ID codes can be programmed, however, one or two programmed ID codes is also possible.

• When programming the ID code into a keyless control module, verify that other transmitters are not being operated in the vicinity.

• After ID code programming, remove the key from the steering lock and verify that all doors lock/unlock normally using the transmitter.

Type B

Applied VIN (assumed):

• JMZ NC1882*# 103860-

• JMZ NC18820# 103860-

• JMZ NC18F2*# 103860-

• JMZ NC18F20# 103860-

• JMZ NC18F6*# 103860-

• JMZ NC18F60# 103860-

• JM0 NC30F100 100546-

Caution

• Always program three ID codes because the programming mode terminates if three ID codes are programmed. At this time, the same transmitter (programmed transmitter) can be programmed two or three times.

Note

• Always program three ID codes because all the programmed ID codes prior to activation are cleared when the programming mode is activated.

• A maximum of three ID codes can be programmed.

• When programming the ID code into a keyless control module, verify that other transmitters are not being operated in the vicinity.

• After ID code programming, remove the key from the steering lock and verify that all doors lock/unlock normally using the transmitter.
