No.
|
Warning and indicator light
|
Input signal source
|
CAN system
|
Note
|
|
1
|
MIL
|
PCM
|
×
|
-
|
|
2
|
ABS warning light
|
• DSC HU/CM
• ABS HU/CM
|
×
|
-
|
|
3
|
DSC OFF light
|
DSC HU/CM
|
×
|
With DSC
|
|
4
|
DSC indicator light
|
DSC HU/CM
|
×
|
With DSC
|
|
5
|
AT warning light
|
TCM
|
×
|
AT
|
|
6
|
Turn indicator light
|
Flasher control module
|
-
|
-
|
|
7
|
Keyless indicator light
|
Keyless control module
|
×
|
With advanced keyless system
|
|
Keyless warning light
|
|
8
|
High-beam indicator light
|
Headlight (HI)
|
-
|
-
|
|
9
|
Security light
|
Keyless control module
|
×
|
-
|
|
10
|
Front fog indicator light
|
Front fog light relay
|
-
|
With front fog light
|
|
11
|
Rear fog indicator light
|
Rear fog light relay
|
-
|
With rear fog light
|
|
12
|
Head light auto leveling warning light
|
Auto leveling control module
|
-
|
With head light auto leveling system
|
|
13
|
Brake system warning light
|
• DSC HU/CM
• ABS HU/CM
|
×
|
-
|
|
• Parking brake switch
• Brake fluid level sensor
|
-
|
-
|
|
14
|
Cruise main indicator light
|
PCM
|
×
|
With cruise control system
|
|
Cruise set indicator light
|
|
15
|
Door ajar warning light
|
Door switches
|
-
|
-
|
|
16
|
Seat belt warning light
|
SAS control module
|
-
|
-
|
|
17
|
Air bag system warning light
|
SAS control module
|
-
|
-
|
|
18
|
Selector indicator light
|
TCM
|
×
|
AT
|
|
19
|
Generator warning light
|
PCM
|
×
|
-
|
|
20
|
Fuel-level warning light
|
Fuel gauge sender unit
|
-
|
-
|
