DOOR LOCK SYSTEM OPERATION RECORD

id091400005000

Purpose

• Stores the record of the user's operation and the door lock system operation corresponding to the user's operation.

Function

• The door lock system operation record is stored by the BCM and displayed using the Mazda Modular Diagnostic System (M-MDS).

• The BCM stores the following when the door lock actuator operates.

― Time and date

― Part or function which output unlock signal

― Part or function which output lock signal

― Operated actuator

― Vehicle condition

Construction

• Based on the stored record, the BCM displays the following operation record on the Mazda Modular Diagnostic System (M-MDS) screen.

amxzzn00000983

Operation

• Based on the lock/unlock signal, the BCM sends an operation signal to the door lock actuator motor, and stores the operation record at the same time.

• Because it takes time from when the door lock actuator motor operates until the lock/unlock is switched, the BCM may store the operation record before the lock/unlock switching is completed.

Fail-safe

• Not applicable
