KEYLESS RECEIVER

id091400109800

Purpose, Function

• Receives ID data and button operation information from the remote transmitter and sends the received ID data and button operation information to the LF control unit.

Construction

• Installed inside the tire house trim.

am3zzn00010051

Operation

1. The ID data and button operation information sent from the remote transmitter is received by the keyless receiver by using electromagnetic wave.

2. The keyless receiver transmits the received ID data and button operation information to the LF control unit by using serial communication.
