•  The PCM determines the engine operation conditions based on input signals and sends an operation signal to the front or rear HO2S.

am3zzn00000364

1	ECT sensor
2	IAT sensor
3	CKP sensor
4	TP sensor
5	MAF sensor
6	Battery
7	Front HO2S heater
8	Rear HO2S heater
9	BARO sensor (If equipped)
