•  The PCM compares the fuel injection amount with the required fuel amount based on input signals and controls the fuel pump speed control relay on/off.

am3zzn00001223

1	ECT sensor
2	IAT sensor
3	MAF sensor
4	CKP sensor
5	Battery
6	Fuel pump speed control relay
