MAIN RELAY [SKYACTIV-G 1.5, SKYACTIV-G 2.0, SKYACTIV-G 2.5]


id0140g5008300


Purpose/Function

•  Supplies power to each part.
•  Supplies battery voltage to each part based on the signals from the PCM even though the ignition is switched on or off.

Construction

•  Installed in the relay and fuse block.
am3zzn00003624

Operation

•  After the contact point is on battery voltage is supplied to the coil based on the signals from the PCM.
am3zzn00003625

Fail-safe

•  Function not equipped.
