Function name
|
Contents
|
|
ABS control function
|
• Controls brake fluid pressure when braking to maintain directional stability, ensure steerability and reduce stopping distance.
|
|
Electronic brakeforce distribution (EBD) control function
|
• Constantly controls proper distribution of brake fluid pressure to the front and rear wheels according to vehicle load, road surface and vehicle speed conditions to prevent early lock-up of the rear wheels.
|
|
TCS control function
|
• Controls traction to within the road surface friction limit and according to road and driving conditions to improve starting and acceleration performance, and safety.
|
|
DSC control function
|
• Suppresses strong over-steer and under-steer tendencies when turning by controlling engine output and braking of each wheel to assure driving safety.
|
|
CAN communication function
|
• Outputs the vehicle speed signal and DSC system warning control data via CAN lines.
|
|
On-board diagnostic system
|
• A function that allows important parts of the DSC control system to perform self-diagnosis. In case a malfunction occurs, the warning lights illuminate to alert the driver, and at the same time a DTC is stored in the DSC HU/CM.
• When a malfunction is determined as a result of the on-board diagnostic test, system control is suspended or limited to prevent any dangerous situation while driving.
|
