DIFFERENTIAL OIL TEMPERATURE SENSOR CONSTRUCTION/OPERATION
id031800166800
• The differential oil temperature sensor is installed in the rear differential carrier.
• The differential oil temperature sensor uses a thermistor whose resistance changes according to changes in the rear differential oil temperature.
• The resistance grows smaller as the oil temperature rises and vice-versa, as shown.
.
|
1
|
Differential oil temperature sensor characteristic
|
|
2
|
Resistance (ohm)
|
|
3
|
Temperature (°C {°F})
|
|
4
|
Larger
|
|
5
|
Higher
|
