RESISTOR INSPECTION
id074000800800
1. Verify that the resistance between the terminals of the resistor is as shown in the table.
• If not as specified, replace the resistor.
Terminal
Resistance (ohm)
A-D
0.21-0.23
A-B
0.60-0.68
A-C
2.29-2.62
