•  The instrument cluster operation record stores the record of the illumination or flashing of the warning light.

•  The operation record is stored by the instrument cluster and displayed using the Mazda Modular Diagnostic System (M-MDS).

•  The instrument cluster stores the following when any of the warning lights illuminates or flashes.

•  Based on the stored record, the instrument cluster displays the following operation record on the M-MDS screen.

ac5uun00000521

•  When the instrument cluster receives a CAN signal or a warning light illumination/flash request signal sent from each switch, it controls the warning light to illuminate/flash and stores the operation record at the same time.

•  Function not equipped.
