DECORATION PANEL DISASSEMBLY/ASSEMBLY

id091700600900

1.  Remove the center ventilator grille. (See VENTILATOR GRILLE REMOVAL/INSTALLATION.)

2.  Remove the hazard warning switch. (See HAZARD WARNING SWITCH REMOVAL/INSTALLATION.)

3.  Disassemble in the order indicated in the table.

am6xuw00007583

1	Screw
2	Partition plate
3	Decoration plate
4	Bezel
5	Screw
6	Center ventilator grille bracket.

4.  Assemble in the reverse order of disassembly.
