REAR SEAT BACK REMOVAL/INSTALLATION [4SD]

id091300920200

1.  Remove the rear seat cushion. (See REAR SEAT CUSHION REMOVAL/INSTALLATION [4SD].)

2.  Remove the rear buckle installation bolt. (See REAR BUCKLE REMOVAL/INSTALLATION.)

3.  Fold the rear seat back.

4.  Remove bolts and nuts.

am6zzw00004590

5.  Remove the rear seat back.

6.  Remove the bolts.

am6zzw00004591

7.  Remove the rear seat back bracket from the rear seat back by pulling the rear seat back bracket in the direction of the arrow shown in the figure.

8.  Install in the reverse order of removal.
