CRUISE CONTROL SWITCH INSPECTION [13B-MSP]

id0120f2800100

1.  Disconnect the negative battery cable and wait for 1 min or more.

2.  Remove the driver‐side air bag module. (See DRIVER-SIDE AIR BAG MODULE REMOVAL/INSTALLATION.)

3.  Disconnect the cruise control switch connector. (See AUDIO CONTROL SWITCH REMOVAL/INSTALLATION.)

4.  Inspect for resistance and continuity between cruise control switch terminals G—F using a tester.

ar8uuw00002591

•  If not as specified, replace the audio control switch. (See AUDIO CONTROL SWITCH REMOVAL/INSTALLATION.)

Switch condition	Resistance (ohm)
ON/OFF button pressed	Continuity
CANCEL button pressed	117—123
SET/COAST button pressed	666—694
RES/ACCEL button pressed	2,156—2,244
No button pressed	No continuity

5.  Apply battery positive voltage to cruise control switch terminal E, and connect terminal D to ground.

ar8uuw00002590

6.  Verify that the LED illuminates.

•  If the LED does not illuminate, replace the audio control switch. (See AUDIO CONTROL SWITCH REMOVAL/INSTALLATION.)
