EGR VALVE CONSTRUCTION/OPERATION [YF (2.0L Zetec)]

BUE011620300N06

• Installed near the throttle body installation area of the intake manifold.


1	EGR valve
1	EGR pipe

• Consists of a diaphragm, spring, and valve.

• The valve operates based on the driving of the diaphragm according to the control vacuum from the EGR control valve.
