No.6 TURN LIGHTS (EITHER SIDE) ILLUMINATED CONTINUOUSLY
id0902h1810800
Possible Cause
• Light switch malfunction
• Related wiring harness malfunction
Diagnostic Procedure
STEP
INSPECTION
ACTION
1
INSPECT LIGHT SWITCH
Disconnect the light switch connector.
Do the turn lights stop flashing?
Yes
Replace the light switch.
No
Go to the next step.
2
INSPECT RELATED WIRING HARNESS SHORT TO POWER SUPPLY
Measure the voltage at light switch terminal E and Q.
Is there voltage?
Yes
Repair the related wiring harness.
No
Replace the flasher control module.
