PID name
|
Input/output signal/Part name
|
Unit/Status
|
Terminal
|
|
CCNT_IC
|
DTC
|
Amount of codes detected
|
-
|
|
DIMMER
|
Panel light control status
|
Increase/ Decrease/ Off
|
-
|
|
DIMMER_S3
|
Dimmer switch
|
-
|
2K
|
|
ENGCOOLAN
|
Engine coolant level
|
LOW/OK
|
-
|
|
FUEL
|
Fuel level
|
%
|
-
|
|
HD_LMP_S3
|
Light switch status
|
Off/ Rfog/ P/ Headlamp/ Invalid
|
-
|
|
INST_VBAT
|
Battery positive voltage
|
V
|
3K
|
|
LFAJAR
|
Driver's seat door lock switch
|
Ajar/ Closed
|
2L
|
|
LFSBELT
|
Driver's seat seat belt retractor switch
|
Buckled/ Unbuckled
|
1K
|
|
ODOMETER
|
Distance travelled
|
km/mile
|
-
|
|
OILPRESS*
|
Oil pressure switch
|
Normal/Low
|
-
|
|
PARK_INPT
|
Parking brake switch
|
P/ Not Park
|
1B
|
|
RES_SW
|
Odometer/tripmeter switch
|
ON/OFF
|
-
|
|
TRANSGEAR
|
Selector lever position
|
P/ Reverse/ Neutral/ Drive 1/ Drive 2/ Drive 3
|
-
|
|
VIC_RESET
|
Odometer/tripmeter switch
|
Reset/ Off
|
-
|
