Item
|
Part operated
|
Operation
|
|
ABS_LAMP*
|
ABS warning light
|
Verify the operation by ON/OFF operation.
|
|
ALL_LAMP
|
All warning/indicator lights
|
|
ALL_SEG
|
All LCD segments
|
|
ANTITHEFT*
|
Security light
|
|
BRK_LAMP*
|
Brake system warning light
|
|
CHIME
|
Alarm
|
|
CLNT_LAMP*
|
Coolant level warning light
|
|
DRIVE
|
Selector indicator light (D range)
|
|
ECT
|
Water temperature gauge
|
|
FUEL
|
Fuel gauge
|
|
FUEL_LOW*
|
Fuel-level warning light
|
|
GEAR_IND
|
Selector indicator light
|
|
ILLUMINAT
|
Panel light control
|
Verify illumination level change by changing the value (%).
|
|
LOW1
|
Selector indicator light (1 range)
|
Verify the operation by ON/OFF operation.
|
|
LOW2
|
Selector indicator light (2 range)
|
|
MIL*
|
Malfunction indicator lamp
|
|
NEUTRAL
|
Selector indicator light (Neutral)
|
|
O_DOFFLMP*
|
O/D OFF indicator light
|
|
PARK
|
Selector indicator light (P range)
|
|
R_FOG_LMP*
|
Rear fog indicator light
|
|
REV
|
Selector indicator light (R range)
|
|
RPM
|
Tachometer
|
|
SBLT_LAMP*
|
Seat belt warning light
|
|
SPEED_WRN*
|
Over speed warning buzzer
|
|
SPEEDSG*
|
Speedometer
|
|
TRIP
|
Odometer/tripmeter
|
