Crankshaft, Engine

Crankshaft

Diameter
Main Journal 71.976 - 72.000 mm (2.8337 - 2.8346 in.)
Rod Journal 54.976 - 55.000 mm (2.1644 - 2.1654 in.)

Journal Taper
Standard (New) 0.005 mm (0.0002 in.) max.
Service Limit 0.010 mm (0.0004 in.)
