Basic Setting (Function 04)

Basic Setting

With engine stopped and ignition switched on, the following operation can be carried out with the function "04 - Basic setting"
- Adaptation of the throttle valve control module to the engine control module, see display group 060.
- Vehicles with automatic transmission: Adaptation of kick down function of accelerator position sensor to engine control module, see Display group 063.

With the engine running, the following operations can be performed with the basic setting function:
- Generation of readiness code (mixture adaptation) Readiness Code, Generating
- Performance of mixture preparation system test Testing and Inspection

Test conditions for operations with engine running
- No DTCs stored in DTC memory
- Engine coolant temperature (ECT) at least 80 degrees C.
- Electrical accessories switched off (coolant fan must not run during the test).
- Air conditioning switched off.
- Vehicles with automatic transmission: Selector lever in position P or N.

Test sequence
- Connect vehicle diagnostic, testing and information system VAS5051, and select vehicle system "01 - Engine electronics" in selection. Ignition must be switched on. Connecting VAS 5051 Scan Tool

or after each required process:
- Start engine.

Display on VAS5051:







- Under -1- select diagnostic function "04 - Basic setting".

Display on VAS5051:







1 - Enter display group
- Enter desired display group number (three figures) in zone -2- and confirm entry by pressing -Q- button.

Example:
- Enter "001" for "display group number 001" and confirm entry with -Q- button.

Display on VAS5051:







1 - Measured values not in basic setting
2 - Measured values in basic setting
3 - Display group X
A - Activate basic setting

NOTE: Basic setting is initiated after pressing the -A- button.

Display on VAS5051:







1 - Display zone 1
2 - Display zone 2
3 - Display zone 3
4 - Display zone 4
- Exit function "04 - Basic setting" by pressing <- button.
