With Manufacturer's Scan Tool

Erase DTC Memory (function 05)


NOTE: If DTC memory cannot be erased, Check DTC Memory again and repair malfunction.


Requirements
- DTC memory checked.
- All malfunctions repaired.

After successful DTC memory check:


Display on VAS5051:







- In selection -1-, click on the diagnostic function "05 - Check DTC Memory".


Display on VAS5051:







1 - no indication (before erasing)
or
- DTC memory erased


NOTE: If indication -1- appears in display field: "DTC memory has not yet been checked", the work sequence was not adhered to correctly. DTC memory can only be erased if DTC memory was checked before.

2 - Note: Perform the function? Note: Data is being erased !
- Press on "OK" -button in display -2-.
- End function "05 - Erase DTC Memory" by pressing on <- button
