Adaptation Channel 41 - Time Since Service
Adaptation (function 10)
individual functions are called up by entering the appropriate adaptation channel numbers (see adaptation table).
NOTE:
- Using measuring value blocks 010, 011, 012 and 015, the values that need to be transferred to the new instrument cluster can be read out before replacement.
- Adaptation channels 42, 43, 44 and 45 (Measuring value blocks 013 ) must be adapted when the instrument cluster is replaced.
- Adaptation channels 60, 61, and 62 are only needed when the instrument cluster communicates with the corresponding BUS system..
- Measuring value blocks 125 and 126 indicate the participants in the powertrain CAN-bus.
- Measuring value block 130 indicates the participants in the comfort system CAN-bus.
- Measuring value block 140 indicates the participants in the information CAN-bus
Adaptation table
Adaptation channel Adaptation function
02 Resetting SRI after service
03 Adaptation of consumption display
04 Language versions of driver information system
09 Odometer
18 Adaptation of auxiliary heater
30 Adaptation of fuel gauge sender
35 Adaptation of engine speed threshold
40 Adaptation For distance driven since service
41 Adaptation For time since service
42 Adaptation For minimum mileage performance
43 Adaptation For maximum mileage performance
44 Adaptation For maximum time interval
45 Adaptation For oil quality
60 Adaptation powertrain CAN-bus
61 Adaptation comfort system CAN-bus
62 Adaptation information CAN-bus
Initiating "Adaptation" function 10
- Initiate output Diagnostic Test Mode of instrument cluster.
Display on VAS5051:
- In selection -1-, select the diagnostic function "10 - Adaptation".
Display on VAS5051
1 - Enter channel number Max. input value = 99
- Enter desired adaptation channel in button field -2- See Adaptation table.
- Press -Q- button to confirm input.
NOTE: After changing an adaptation value or ending an adaptation channel, "10 - Adaptation" function must be selected again before selecting another adaptation channel!
Display on VAS5051:
1 - Channel X read and test
2 - Text display of selected channel or No indication
5 - The sliding bar is positioned on the current adaptation value
A - Changing adaptation value using sliding bar:
Display on VAS5051:
- Move sliding bar -5- into desired direction or press on the surface beside the sliding bar, to move it in the desired direction.
- Press "Save" button -4-.
NOTE: If the "Save" button is not indicated on display, only a direct input via the keypad is possible.
Display on VAS5051:
1 - Channel X save
2 - Text display of selected channel or No indication
4 - original value X new value X
- Confirm new adaptation value by pressing the "take over" button -3-.
Display on VAS5051:
1 - Channel X Value X stored
- End function "10 - Adaptation" by pressing <- button.
B - Change adaptation value via direct input:
Display on VAS5051:
- Press "Keypad" button -3-.
Display on VAS5051:
1 - Enter adaptation value input value 0 to 65535
- Enter 5-digit adaptation value in button field -2-. If necessary, insert zeros in front.
Example:
Desired input value: 1
Keypad input: 00001
- Press -Q- button to confirm input.
Display on VAS5051:
1 - Channel X save
2 - Text display of selected channel or No indication
4 - original value X new value X
- Confirm new adaptation value by pressing the "take over" button -3-.
Display on VAS5051:
1 - Channel X Value X stored
- End function "10 - Adaptation" by pressing <- button.
Adaptation channel 41 - time since service
This function is used to input the time in days since the last service.
Display on VAS5051
- Select function "4" in button field -2- For Adaptation channel 41" and press Q button to confirm input.
Display on VAS5051:
1 - Channel 41 read and test
2 - Actual value In spec. in 1 Days
3 - Keypad - only direct input via the keypad is possible
4 - The sliding bar is positioned on the current adaptation value, e.g. 110 Time in days since last service is displayed (here For example 110 represents 110 days)
NOTE:
- Input of the current specified value is only possible in units of one day, indication in display also changes by units of one day.
- When replacing instrument cluster, observe.
- Change adaptation value via direct input See "B - Change adaptation value via direct input".
- Enter 5-digit adaptation value. Insert zeros in front.
Example:
Desired input value: For example 200 days
Keypad input: 00200
Display on VAS5051 after performed adaptation:
1 - Channel 41 Value 200 stored
- End function "10 - Adaptation" by pressing <- button.
