End Output (Function 06)

End Output (function 06)

Requirements:
- DTC memory checked and erased, basic setting performed and coding checked

NOTE: The currently valid code transmitted by the Instrument Cluster Control Module J285 is displayed in the measuring value block (display group "019"). Measuring Value Blocks (Function 08)







Indicated on display of Diagnostic Operation System VAS 5051A
- Select function "06 - End of output".







- Wait until this display (start menu) appears on Diagnostic Operation System VAS 5051A.
- Switch off ignition and disconnect diagnostic connector.
