Measured Value Block, Reading

Measured Value Block, Reading

Test requirements:
- Engine coolant temperature at least 80 degree C.
- Electrical accessories switched off (coolant fan must not run during the test).
- Air conditioning switched off.

Test sequence
- Connect vehicle diagnostic, testing and information system VAS5051 and select vehicle system "01 - Engine electronics" in selection. Ignition must be switched on.

or after each required process:
- Start engine.







Display on VAS5051:
- Under -1- select diagnostic function "08 - Read measured value block".







Display on VAS5051:
1. Enter display group: max. input value = 255

- Enter desired display group number (three figures) in zone -2- and confirm entry by pressing -Q- button.

NOTE: The choice of display group depends on the particular functions and components to be tested.







Display on VAS5051:
1. Read Measured Value Block
2. Display zone 1
Display zone 2
Display zone 3
Display zone 4
3. Display group X

- Exit function "08 - Read measured value block" by pressing button.

NOTE:
- If no display follows, a display field is not assigned.
- To switch to a different display group, proceed as follows:

Display group VAS5051 tester
Higher Press s button.
Lower Press t button.

- Press square button to end function "08 - Read measuring value block".
