Diagram 64/7 (Tracks 71-84)

IMPORTANT NOTE:
This manufacturer uses "Track" style wiring diagrams.
For information on how to use these diagrams effectively, please refer to Diagram Information and Instructions. Diagram Information and Instructions


Engine Control Module (ECM), Cylinder 5 and 6 Fuel Injectors, Ignition Coils 5 and 6 with Power Output Stage, Throttle Position (TP) Sensor, Throttle Valve Control Module





ws = white
sw = black
ro = red
br = brown
gn = green
bl = blue
gr = grey
li = lilac
ge = yellow
or = orange
rs = pink

G79 - Throttle Position (TP) Sensor Locations

G185 - Accelerator Pedal Position Sensor 2 Locations

G186 - Throttle Drive (for Electronic Power Control (EPC)

G187 - Throttle Drive Angle Sensor 1 (for Electronic Power Control (EPC)

G188 - Throttle Drive Angle Sensor 2 (for Electronic Power Control (EPC)

J338 - Throttle Valve Control Module 3.2L CALA / BKH Overviews

J623 - Engine Control Module (ECM) Overview of Control Modules

N83 - Cylinder 5 Fuel Injector 3.2L CALA / BKH Overviews

N84 - Cylinder 6 Fuel Injector 3.2L CALA / BKH Overviews

N323 - Ignition Coil 5 with Power Output Stage 3.2L CALA / BKH Overviews

N324 - Ignition Coil 6 with Power Output Stage 3.2L CALA / BKH Overviews

P - Spark Plug Connectors

Q - Spark Plugs

T14c - 14-Pin Connector, black, in left engine compartment

T17o - 17-Pin Connector, brown, connector station electronics box in left plenum chamber Overview of Connector Stations and Connectors

T60a - 60-Pin Connector, black (Connector A), on engine control module (ECM)

T94a - 94-Pin Connector, black (Connector B), on engine control module (ECM)

(131) - Ground Connection 2 (in engine compartment wiring harness)

(132) - Ground Connection 3 (in engine compartment wiring harness)

(D103) - Connection 3 (in engine compartment wiring harness)

* - Models with automatic transmission 09L

** - Models with automatic transmission 01J
