Diagram 48/13 (Tracks 155-168)






IMPORTANT NOTE:
This manufacturer uses "Track" style wiring diagrams.
For information on how to use these diagrams effectively, please refer to Diagram Information and Instructions. Diagram Information and Instructions


Signal system DKL criminal investigation





ws = white
sw = black
ro = red
br = brown
gn = green
bl = blue
gr = grey
li = lilac
ge = yellow
or = orange
rs = pink

E505 - Special Signals Switch-Over Button

E507 - Special Signals Control Head

J616 - Signals System Control Module

T2ae - Double Connector, left A-pillar, flashing light

T2af - Double Connector, right A-pillar, flashing light

T6ad - 6-Pin Connector, on special signals control head

T10ae - 10-Pin Connector, interchange connector center console

T10af - 10-Pin Connector, on special signals control head

T17l - 17-Pin Connector, brown, connector station A-pillar, right Overview of Connector Stations and Connectors

T33 - 33-Pin Connector, on signals system control module

(43) - Ground Connection (on right lower A-pillar) Overview of Ground Connections in Interior of Vehicle

(44) - Ground Connection (on left lower A-pillar) Overview of Ground Connections in Interior of Vehicle

(51) - Ground Connection (in luggage compartment, right) Overview of Ground Connections in Interior of Vehicle

(X78) - Connection 1 (in optional equipment wiring harness)

* - Criminal investigation with alarm rotary pull switch

** - Criminal investigation with special signals control head (BE200)

Previous Diagram 48/12 (Tracks 141-154)

Next Diagram 48/14 (Tracks 169-182)
