Rear Axle

Vehicle Ride Height - Rear Axle







Observe The Following Test Conditions Prior To The Chassis / Wheel Alignment Check:

1. Correct and identical rim and tyre sizes.
2. Correct tread depth. The tread depth for each axle may differ from left to right by max. 3-4 mm.
3. Correct tyre inflation pressure ( see instruction plate on car ).
4. Wheel bearing clearance OK
5. Steering backlash OK
6. Condition of suspension and shock absorbers OK
7. Car with ride level control: Pull fuse of air supply unit so that there is no controlling down or up.
