Remove or Disconnect
Description:
Description:
REMOVE OR DISCONNECT ^
Disable the SIR system. Refer to Disabling the SIR System.
Service and Repair 1.
Passenger front seat.
2.
Passenger front carpet retainer, then roll back the carpet.
3.
Connector Position Assurance (CPA) and the electrical connector.
4.
Fasteners from the inflatable restraint Sensing and Diagnostic Module
(SDM). 5.
SDM from the vehicle.
