33. Valve Rocker Arm Removal - Right Side

Valve Rocker Arm Removal - Right





Important: Ensure each camshaft follower remains matched to the original stationary hydraulic lash adjuster (SHLAs) and original location the components were assembled in.

1. Remove the camshaft followers from the right cylinder head.
2. Store the camshafts, followers and SHLAs in a clean, secure location.
