Input Shaft Bearing Retainer Assembly

Remove or Disconnect (Figure 34)

Tools Required:
J 29369-2 Input Shaft Bearing Retainer Oil Seal Remover
J 23907 Slide Hammer
J 25070 Heat Gun
J 36504 Input Shaft Bearing Oil Seal Installer

Seal Replacement
1. Rubber seal lip with pliers.

^ Exposing the metal lip:

A. Install J 29369-2 below metal lip of seal.
B. Expand to finger tight.
C. Turn five additional turns.
D. Install J 23907 into J 29369-2.

2. Input shaft bearing retainer oil seal (209).

A. Heat oil seal with J 25070 for minimum of 3 minutes.
B. Hold the clutch release bearing pilot with a heat resisting glove or equivalent. Remove the seal with a slide hammer.

3. Gasket material from the retainer (206) using liquid gasket remover.

Inspect

1. Clutch release bearing pilot for scoring, wear, or cracks, especially at the flange.
2. Retainer for wear or damage.





Install or Connect (Figure 35)

1. NEW oil seal (209) using J 36504.

^ Fill between the seal lip with chassis grease.
