Inflator Module - Replacement

Remove or Disconnect
1. Disable SIR system.
2. Four bolts/screws from backside of steering wheel.
3. Inflatable restraint steering wheel module.
4. Electrical connections from inflatable restraint steering wheel module.


Install or Connect
1. Electrical connections to inflatable restraint steering wheel module.
2. Inflatable restraint steering wheel module.
3. Bolts/screws to inflatable restraint steering wheel module.
^ Tighten bolts/screws to 20 Nm (14 lb ft).
4. Enable SIR system.
