Generator Bracket Replacement

REMOVAL PROCEDURE

CAUTION: Refer to Battery Disconnect Caution in Cautions and Notices.

1. Remove the generator.
2. Remove the power steering pump.
3. Remove the generator bracket bolts.
4. Remove the generator bracket from the cylinder head.

INSTALLATION PROCEDURE
1. Install the generator bracket to the cylinder head.

Tighten
Tighten the generator bracket bolts to 50 N.m (37 lb ft).

2. Install the power steering pump.
3. Install the generator.
