Parking Brake System: Adjustments
Park Brake Adjustment 1.
Fully apply and release the parking brake (1) 4 to 6 times in order to self adjust the brake.
2.
The parking brake (1) is self adjusting, however, if the parking brake tension is in question, refer to Drum Brake Adjustment.
