OnStar Button Assembly Replacement
ONSTAR BUTTON ASSEMBLY REPLACEMENTREMOVAL PROCEDURE
1. Using a small flat bladed tool, pry the OnStar(R) bezel tab down away from the overhead console.
2. Remove the overhead console.
3. Disconnect the OnStar(R) electrical connectors.
4. Remove the 2 screws that retain the OnStar(R) bezel to the overhead console.
5. Remove the OnStar(R) button assembly from the overhead console.
INSTALLATION PROCEDURE
1. Install the OnStar(R) button assembly to the overhead console.
2. Install the 2 screws that retain the OnStar(R) bezel to the overhead console.
3. Reconnect the OnStar(R) electrical connectors.
4. Install the overhead console.
5. Snap the OnStar(R) button assembly back into place in the overhead console.
