Backup Lamp: Service and Repair

BACKUP LAMP REPLACEMENT

REMOVAL PROCEDURE

1. Open the rear compartment.
2. Remove the bulb/socket from the backup lamp.
3. Remove the bulb from the socket, if required.

INSTALLATION PROCEDURE

1. Install the bulb to the socket, if required.
2. Install the bulb/socket to the backup lamp.
3. Connect the electrical connector to the backup lamp.
4. Position the backup lamp to the rear compartment lid.
5. Close the rear compartment.
