Exhaust Manifold
Exhaust Manifold to Cylinder Head Nut 12 Nm (9 ft. lbs.)
Exhaust Manifold to Cylinder Head Stud 10 Nm (89 inch lbs.)
Exhaust Manifold Pipe Flange Stud 16 Nm (12 ft. lbs.)
Heat Shield to Exhaust Manifold Bolt 10 Nm (89 inch lbs.)
Exhaust Manifold to Cylinder Head Nut 12 Nm (9 ft. lbs.)
Exhaust Manifold to Cylinder Head Stud 10 Nm (89 inch lbs.)
Exhaust Manifold Pipe Flange Stud 16 Nm (12 ft. lbs.)
Heat Shield to Exhaust Manifold Bolt 10 Nm (89 inch lbs.)
