Mirror Replacement

MIRROR REPLACEMENT

REMOVAL PROCEDURE




1. Remove the front door trim panel.
2. Remove the trim cover.
3. Disconnect the electrical connectors (1).
4. Remove the nuts from the mirror (2).
5. Remove the mirror from the front door (3).

INSTALLATION PROCEDURE




1. Position the mirror to the front door (3).
2. Install the nuts to the mirror, starting at the lower left nut (2).

NOTE: Refer to Fastener Notice in Service Precautions.

Tighten the outside mirror nuts to 10 N.m (89 lb in).

3. Connect the electrical connectors (1).
4. Install the trim cover.
5. Install the front door trim panel.
