Home >> Chevrolet >> 2013 >> Equinox AWD L4-2.4L >> Repair and Diagnosis >> Transmission and Drivetrain >> Automatic Transmission/Transaxle >> Diagrams >> Fluid Diagrams >> 6T30/6T40/6T45/6T50 - Automatic Transmission >> Drive Range - Fourth Gear Default (Gen 2/Hybrid)

Drive Range - Fourth Gear Default (Gen 2/Hybrid)





Drive Range, Fourth Gear Default - Gen 2/Hybrid
