Installation

INSTALLATION





1. Position the lock cylinder (2) and gasket to the liftgate (1).
2. Install the retainer clip that secures the lock cylinder to the liftgate. Make sure the retainer clip is fully engaged to the lock cylinder.
3. Install the latch control Latch Control - Installation.
4. Reconnect the negative battery cable.
5. Verify liftgate lock cylinder and latch operation.
