P1775

P1775 - SOLENOID SWITCH VALVE LATCHED IN TCC POSITION

When Monitored and Set Condition:
P1775 - SOLENOID SWITCH VALVE LATCHED IN TCC POSITION

When Monitored: During an attempted shift into 1st gear.

Set Condition: This code is set if three unsuccessful attempts are made to get into 1st gear in one given key start.

POSSIBLE CAUSES:
RELATED DTC P1784 PRESENT
INTERMITTENT WIRING & CONNECTORS
INCORRECT FLUID LEVEL
L/R PRESSURE SWITCH SENSE CIRCUIT OPEN
TRANSMISSION RELAY OUTPUT CIRCUIT OPEN
L/R PRESSURE SWITCH SENSE CIRCUIT SHORT TO GROUND
L/R PRESSURE SWITCH SENSE CIRCUIT SHORT TO VOLTAGE
INTERNAL TRANSMISSION - SOLENOID SWITCH VALVE STUCK
TCM - L/R PRESSURE SWITCH
