Missing Transmission Position Input

SYMPTOM MISSING TRANSMISSION POSITION INPUT
When Monitored and Set Condition: MISSING TRANSMISSION POSITION INPUT
- When Monitored: Continuously with ignition on.
- Set Condition: This condition occurs when the Transfer Case Control Module stops receiving a bus message for Transmission Position for the period of 5 seconds.

POSSIBLE CAUSES
- CLUSTER DTC'S PRESENT
- INTERMITTENT WIRING AND CONNECTORS
- TCM DTC PRESENT
- CONDITION PRESENT
- PCM COMMUNICATION DTC'S PRESENT
