40TE Automatic Transaxle
SPECIAL TOOLS
Figure 1 Puller C-637
Figure 2 Pressure Gauge (High) C-3293SP
Figure 3 Dial Indicator C-3339
Figure 4 Oil Pump Puller C-3752
Figure 5 Seal Puller C-3981B
Figure 6 Universal Handle C-4171
Figure 7 Seal Installer C-4193A
Figure 8 Adapter C-4996
Figure 9 Remover Kit L-4406
Figure 10 Gear Puller L-4407A
Figure 11 Bearing Installer L-4410
Figure 12 Gear Checking Plate L-4432
Figure 13 Bearing Puller L-4435
Figure 14 Differential Tool L-4436A
Figure 15 Special Jaw Set L-4518
Figure 16 Installer L-4520
Figure 17 Thrust Button L-4539-2
Figure 18 Adapter L-4559
Figure 19 Adapter L-4559-2
Figure 20 Bearing Splitter P-334
Figure 21 Puller Set 5048
Figure 22 Remover/Installer 5049-A
Figure 23 Installer 5050A
Figure 24 Installer 5052
Figure 25 Compressor 5058A
Figure 26 Compressor 5059-A
Figure 27 Installer 5067
Figure 28 Pliers 6051
Figure 29 Installer 6052
Figure 30 Installer 6053
Figure 31 Button 6055
Figure 32 Plate 6056
Figure 33 Disk 6057
Figure 34 Installer 6061
Figure 35 Remover 6062-A
Figure 36 Holder 6259
Figure 37 Bolt 6260
Figure 38 Installer 6261
Figure 39 Tip 6268
Figure 40 Remover/Installer 6301
Figure 41 Remover/Installer 6302
Figure 42 Installer 6536-A
Figure 43 Puller 7794-A
Figure 44 End Play Socket Set 8266
Figure 45 Input Clutch Pressure Fixture 8391
